Single Manual Grinding Machine

SV200

Specifically designed for removing the residual resin after plugging.

Introductions





Descriptions

Designed for residual grinding of PCB boards after grinding, using vacuum adsorption technology to fix the PCB board on the table, manually pull the grinding head to a specific position and drive it to rotate in order to partially grind the PCB board.

Features

Grinding area (size) and precision can be switched quickly.

Easy switching between dry/wet grinding modes.

Replace the traditional manual grinding, accurate control of copper thickness accuracy.

The grinding current is accurately displayed on a high precision digital ammeter.

Specifications

Equipment Size

1808*1434*1815mm

Panel Size

Min: 12*14In(304.8*356mm)

Max: 21*30In(536*762mm)

Thickness of substrate

0.3-15mm

Grinding accuracy

0.25mil(MAX.)

Speed of grinding head

1000/2000/3000rpm

Working Height

1125mm

Make-up pipe calibre

20mm(4分管/4-point pipe)

Communal Requirement

Electricity needs

Electronic

AC380V;3P+N+PE,50Hz

Power (output)

5KW

Required amount of air pressure

≥0.6MPa;φ8mm(dry air)

Recommended space around machine

800mm

Weight

675KG

Equipment installation environment

 (temperature, humidity and

dust-free requirements)

Clean room

Temperature requirement: 22±2℃

Humidity requirement: 50±5%
